SOLIDWORKS Simulation Premium: Nonlinear - Instructor Led Online Training
159500
SOLIDWORKS Simulation Premium: Nonlinear - Instructor Led Online Training
159500
**ADD COURSE TO CART TO SEE UPCOMING DATE**
Length: 3 days; 9:00am to 1:00pm PST
Prerequisites: Must have attended the basic SOLIDWORKS Simulation Premium class, or have similar experience with SOLIDWORKS and working basic knowledge of finite elements, basic mechanical principles and basic principles in Vibrations.
Description: This class will raise your SOLIDWORKS Simulation FEA skills to the next level. It offers hands-on experience for the SOLIDWORKS Simulation Premium nonlinear module. It provides an overview on a wide range of nonlinear structural/mechanical analysis topics. You will learn how to deal with models that exhibit large displacements and/or yielding, discuss and practice the use of many material models available in SOLIDWORKS Simulation and how to drive a non-linear analysis to successful completion.
Topics covered in this course:
Lesson 1:
Large Displacement Analysis
- Case Study: Hose Clamp
- Linear Static Analysis
- Nonlinear Static Study
- Linear Static Study (Large Displacement)
Lesson 2:
Incremental Control Techniques
- Case Study: Trampoline
- Linear Analysis
- Nonlinear Analysis - Force Control
- Nonlinear Analysis - Displacement Control
Lesson 3:
Nonlinear Static Buckling Analysis
- Case Study: Cylindrical Shell
- Linear Buckling
- Linear Static Study
- Nonlinear Symmetrical Buckling
- Nonlinear Asymmetrical Buckling
Lesson 4:
Plastic Deformation
- Case Study: Paper Clip
- Linear Elastic
- Nonlinear - von Mises
- Nonlinear - Tresca’s
Lesson 5:
Hardening Rules
- Case Study: Crank Arm
- Isotropic Hardening
-
Kinematic Hardening
Lesson 6:
Analysis of Elastomers
- Case Study: Rubber Pipe
- Two Constant Mooney-Rivlin (1 Material Curve)
- 2 Constant Mooney-Rivlin (2 Material Curves)
- 2 Constant Mooney-Rivlin (3 Material Curves)
- 6 Constant Mooney-Rivlin (3 Material Curves)
Lesson 7:
Nonlinear Contact Analysis
- Case Study: Rubber Tube
Lesson 8:
Metal Forming
- Bending
- Case Study: Sheet Bending
Items included with course (to be sent to the shipping address provided):
SOLIDWORKS training manual
